Orenco PVU953625L Biotube Pump Vault w/Long Support Pipes

Orenco PVU953625L Biotube Pump Vault w/Long Support Pipes

Original price was: $908.54.Current price is: $507.15.

SKU: ONCPVU95-3625-L Category:

Description

Orenco Biotube® pump vaults are used to transport filtered effluent from septic tanks or separate dosing tanks in effluent pumping systems. They are a critical component of individual onsite systems and effluent sewer collection systems. Pump vaults house a Biotube effluent filter and one or two Orenco high-head effluent pumps and can be used in single-compartment septic tanks with flows up to 40 gpm. When flows are greater than 40 gpm, a double-compartment septic tank or separate dosing tank is recommended. Pump vaults are 12 in. in diameter, and accommodate one pump (simplex) or two pumps (duplex). Each pump vault comes with a Biotube filter cartridge, vault housing, support pipes, and float bracket to hold the float assembly. Custom lengths can be produced.

Orenco PVU953625L Biotube Pump Vault Typical Application

  • Residential septic tank effluent
  • Commercial septic tank effluent
  • Dose tank high head pumping
  • Treatment system pumping
  • Other effluent pumping where screening is needed

Orenco PVU953625L Biotube Pump Vault Technical Details

  • Molded polyethylene housing
  • Long support pipes for 30″ risers (can be cut down for smaller risers)
  • Provides flow inducer for high-head turbine style pumps
  • 19.7 sq ft screen area
  • 5.9 sq ft flow area
  • 0.125 (1/8″) in opening Biotube filter
  • Extendible handle for easy removal
  • Filter can be removed without pulling the pump or vault
  • Easy to clean by simply hosing off whenever the tank needs pumping
  • Removes suspended solids extending drainfield life
  • Corrosion-proof construction to ensure long life
