Orenco PVU952419 Biotube Pump Vault

Orenco PVU952419 Biotube Pump Vault

Original price was: $947.64.Current price is: $528.56.

SKU: ONCPVU95-2419 Category:

Description

Orenco Biotube® pump vaults are used to transport filtered effluent from septic tanks or separate dosing tanks in effluent pumping systems. They are a critical component of individual onsite systems and effluent sewer collection systems. Pump vaults house a Biotube effluent filter and one or two Orenco high-head effluent pumps and can be used in single-compartment septic tanks with flows up to 40 GPM. When flows are greater than 40 GPM, a double-compartment septic tank or separate dosing tank is recommended. Pump vaults are 12 in. in diameter, and accommodate one pump (simplex) or two pumps (duplex). Each pump vault comes with a Biotube filter cartridge, vault housing, support pipes, and float bracket to hold the float assembly. Custom lengths can be produced.

Orenco PVU952419 Biotube Pump Vault Typical Application

  • Residential Septic Tank Effluent
  • Commercial Septic Tank Effluent
  • Dose Tank High Head Pumping
  • Treatment System Pumping
  • Other Effluent Pumping where Screening is Needed

Orenco PVU952419 Biotube Pump Vault Technical Details

  • Molded Polyethylene Housing
  • Provides Flow Inducer for High-Head Turbine Style Pumps
  • 14.5 sq ft Screen Area
  • 4.4 sq ft Flow Area
  • 0.125 (1/8″) in Opening Biotube Filter
  • Extendible Handle for Easy Removal
  • Filter can be Removed Without Pulling the Pump or Vault
  • Easy to Clean by Simply Hosing Off Whenever the Tank Needs Pumping
  • Removes Suspended Solids Extending Drainfield Life
  • Corrosion-Proof Construction to Ensure Long Life
